Touch Screen
Automatically records the melting curve
Room temperature ~ 400 ℃
Characteristics
Measurement of melting point is one of the important methods of measurement of purity;
To be used in production of medicines, dye-stuffs, perfumes and other organic crystal substances;
Use PID & PWM to control the temperature;
Automatically records the melting curve;
Touch Screen
USB and RS232
Technical Data
Melting-point measurement range: | room temperature ~ 400 ℃ |
Setting rate of the “starting temperature”: | 50℃~400℃≤ 5 mins; 400℃~50℃≤7 mins |
Minimum digital display: | 0.1 ℃ |
Size of the capillary: | φ1.4mm(outside diameter)
φ1.0mm(inside diameter), 90mm |
Loading height of the sample: | 3mm-5mm |
Linear heating-up rate: | 0.1 ℃ ~20 ℃ /min |
Repeatability: | 0.3 ℃ |
Accuracy: | ≤200 ℃: 0.4℃; >200 ℃: 0.7℃ |
