Features:
1. New generation Peltier technology, with ramping rate at 6 °C/sec.
2. Core parts from famous supplier, ensure Temp. uniformity and accuracy.
3. English interface. A wealth of software features to enjoy.
4. Wide range of module options, easily interchangeable modules no tools required.
5. 15,000 on board protocol storage and unlimited storage by flash drive.
6. Global universal switch power (85V-265V, 50-60Hz).
7. Innovative design, multiple patent protection.
Technical data:
| Model | GTC-A300 |
| Optional Module | 96 Module:96wells×0.2ml
9677Module:96wells×0.2ml+77wells×0.5ml Multi－purpose Module:9677Module+In-situ Adapter 384Module:384wells |
| Heating＆Cooling Technology | New generation Peltier technology allow 1,000,000 cycles |
| Display | 7’’Color Touch Screen, real-time graphical display |
| Language | English |
| USB flash drive Function | Unlimited storage of protocols with USB flash drive |
| Communication Ports | 2 USB&1 LAN |
| Venting System | Front air in ＆back air out, two cyclers can be placed side by side |
| TEMPERATURE | |
| Block Temp. Rang | 0℃－105℃ |
| Max.Heating Rate | 6℃/s |
| Max.Cooling Rate | 5℃/s |
| Temp.Uniformity | ≤±0.2℃ |
| Temp.Accuracy | ≤±0.1℃ |
| Display Resolution | 0.1℃ |
| Ramping Rate Adjustable | 0.1－4.0℃ |
| Mode Of Temp.Control | Sim－tube＆ Block mode |
| GRADIENT | |
| Gradient Accuracy | ≤±0.1℃ |
| Column Uniformity | ≤±0.2℃ |
| Gradient Range | 30℃－99.9℃ |
| Temp.Differential Range
Gradient Capability |
Max.30℃ |
| 12Column | |
| HEAT LID | |
| Height Of Heat Lid | Steplessly adjustable lid, accommodates PCR tubes, strips ＆plates |
| Lid Feature | Innovative“TOP-OPEN “technology,protection from over-pressure |
| Heat Lid Temp.Range | 30℃－112℃ |
| Auto Shut-off | Lid will shut off automatically when the block Temp.falls below set Temp |
| SOFTWARE | |
| Max.Number Of Programs | Max.15, 000 programs onboard, unlimited storage of protocols with USB flash drive |
| Max.Step | 30 Steps, multiple nesting cycles available |
| Max.Cycle | 100 Typical Cycles,max.10,000nesting cycles |
| Time.Increment/decrement | 1-120 sec, available for Long PCR |
| Temp.Increment/decrement | 0.1-10.0℃, available for Touchdown PCR |
| Auto Pause/ Auto Restart | Yes |
| Multi-user Log In | With Password-based authentication to protect personal protocols |
| Tm Calculator | Automatically calculates the melting ＆annealing Temp.Of a pair of primers |
| Hold at 4℃ | A below ambient temp. incubation allow PCR products storage overnight |
| Program Wizard | Pre-program templete make the editing very easy through modify several parameters |
| Running Report | Provide detailed reports of previously run protocols |
| PC Connection | Remote PC control to manage multiple units across the LAN network |
| OTHER FEATURES | |
| Power | Global switch power supply:85V-265V,50-60Hz |
| Consumption | 600w |
| Dimensions(L×W×H) | 362×256×255mm |
| Net Weight | 7.3KG |
